Heavy Duty Lathe Machine - HD 381

250000 INR/Unit

Get a Price/Quote

Product Details:

Product Type Horizontal
Material CI CAST
CNC Or Not Normal
Automatic Grade Semi Automatic
Control System Other
Max. Swing Diameter 200-2000 Millimeter (mm)
Voltage 440 Volt (v)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Heavy Duty Lathe Machine - HD 381 Price And Quantity

Price 250000 INR/Unit
Price Range 250000.00 - 1000000.00 INR/Unit
Minimum Order Quantity 1 Piece

Heavy Duty Lathe Machine - HD 381 Product Specifications

Color BLUE AND GREY
Voltage 440 Volt (v)
Feature Simple Control
Automatic Grade Semi Automatic
CNC Or Not Normal
Max. Swing Diameter 200-2000 Millimeter (mm)
Warranty 1 YEAR
Material CI CAST
Weight (kg) 1.5 TO 7 Tonne
Control System Other
Product Type Horizontal

Heavy Duty Lathe Machine - HD 381 Trade Information

Supply Ability 30 Piece Per Month
Delivery Time 1 Week

Product Description

The lathe machine is a versatile industrial machine that finds a place in paper mill, sugar mill, automobile factory and over & above all general engineering maintenance workshop. This industrial machine can also be supplied in different other models with different specifications and features. The other industrial sectors that involve engineering use this lathe machine such as aerospace and textile. The applications for this machine is used are manufacturing automobile components, making rubber roller, die works, turning, threading, and more.

BED	HD-1	HD-2	HD-3	HD-4	HD-5	HD-6	HD-7
Length of Bed	7'(2135)	9'(2745)	10'(3040)	12'(3655)	14'(4270)	16'(4875)	18'(5472)
Width of Bed	15"(381)	15"(381)	15"(381)	15"(381)	15"(381)	15"(381)	15"(381)
Length of Gap	6"(150)	6"(150)	6"(150)	6"(150)	6"(150)	6"(150)	6"(150)
Length of Gapin Front of Fce Plate	8"(205)	8"(205)	8"(205)	8"(205)	8"(205)	8"(205)	8"(205)

CAPACITY	HD-1	HD-2	HD-3	HD-4	HD-5	HD-6	HD-7
Height of Centre	15"(381)	15"(381)	15"(381)	15"(381)	15"(381)	15"(381)	15"(381)
Swing Ove Bed	28.75"(730)	28.75"(730)	28.75"(730)	28.75"(730)	28.75"(730)	28.75"(730)	28.75"(730)
Swing Over Cross Slide	22"(550)	22"(550)	22"(550)	22"(550)	22"(550)	22"(550)	22"(550)
Swing In Gap	42"(1050)	42"(1050)	42"(1050)	42"(1050)	42"(1050)	42"(1050)	42"(1050)
Admin Between Centre	39.37"(1000)	63.37"(1600)	75.37"(1905)	99.37"(2515)	123.37"(3125)	147.37"(3735)	170"(4300)
Movement of Cross Slide	15"(381)	15"(381)	15"(381)	15"(381)	15"(381)	15"(381)	15"(381)
Movement of Compound Slide	5"(125)	5"(125)	5"(125)	5"(125)	5"(125)	5"(125)	5"(125)

MAIN SPINDLE	HD-1	HD-2	HD-3	HD-4	HD-5	HD-6	HD-7
Spindle Nose	100 x 6 TPI	100 x 6 TPI	100 x 6 TPI	100 x 6 TPI	100 x 6 TPI	100 x 6 TPI	100 x 6 TPI
Spindle Bore	80mm	80mm	80mm	80mm	80mm	80mm	80mm
Taper Bore	MT-6	MT-6	MT-6	MT-6	MT-6	MT-6	MT-6

TAIL STOCK SPINDLE	HD-1	HD-2	HD-3	HD-4	HD-5	HD-6	HD-7
Diameter	2.25"(57)	2.25"(57)	2.25"(57)	2.25"(57)	2.25"(57)	2.25"(57)	2.25"(57)
Morse Taper	MT-4	MT-4	MT-4	MT-4	MT-4	MT-4	MT-4
Travel	7"(178)	7"(178)	7"(178)	7"(178)	7"(178)	7"(178)	7"(178)

SPEED	HD-1	HD-2	HD-3	HD-4	HD-5	HD-6	HD-7
No. of Speed	8	8	8	8	8	8	8
RPM Low & High	25 to 380	25 to 380	25 to 380	25 to 380	25 to 380	25 to 380	25 to 380

THREADS	HD-1	HD-2	HD-3	HD-4	HD-5	HD-6	HD-7
Metric Thread	13/ 1mm to 6mm	13/ 1mm to 6mm	13/ 1mm to 6mm	13/ 1mm to 6mm	13/ 1mm to 6mm	13/ 1mm to 6mm	13/ 1mm to 6mm
Inch Thread	19/ 2 to 24 TPI	19/ 2 to 24 TPI	19/ 2 to 24 TPI	19/ 2 to 24 TPI	19/ 2 to 24 TPI	19/ 2 to 24 TPI	19/ 2 to 24 TPI
Lead Screw Dia	38mm / 4TPI	38mm / 4TPI	38mm / 4TPI	38mm / 4TPI	38mm / 4TPI	38mm / 4TPI	38mm / 4TPI

ELECTRIC	HD-1	HD-2	HD-3	HD-4	HD-5	HD-6	HD-7
Motor Power	5 HP III Phase	5 HP III Phase	5 HP III Phase	5 HP III Phase	5 HP III Phase	5 HP III Phase	5 HP III Phase

DRIVE	HD-1	HD-2	HD-3	HD-4	HD-5	HD-6	HD-7
Counter to Spindle	C-72	C-72	C-72	C-72	C-72	C-72	C-72
Counter to Motor	B-72	B-72	B-72	B-72	B-72	B-72	B-72

GENERAL	HD-1	HD-2	HD-3	HD-4	HD-5	HD-6	HD-7
Floor Space (L x W x H)	2850x1400x1700	3350x1400x1700	3700x1400x1700	4300x1400x1700	5000x1400x1700	5550x1400x1700	6100x1400x1700
